The Chauvin Arnoux E27 clamp meter adapter is a versatile current converter suitable for A/AC and A/DC readings ranging from 100 mA to 100 A. Utilising its Rogowski coil design, it delivers accurate measurements essential for electrical analysis and diagnostics. Typical applications include monitoring electrical circuits and systems in industrial or commercial settings.
| Type |
Clamp meter adapter |
| A AC reading range (min.) |
100mA |
| A DC reading range (max.) |
100A |
| Amperage reading range AC (max.) |
100A |
| Amperage reading range DC (min.) |
100mA |
| Calibrated to |
Manufacturer's standards (no certificate) |
| Dim |
(L x W x H) 231 x 67 x 36 mm |
| Height |
36mm |
| Length |
231mm |
| Max. frequency |
100kHz |
| Opening range of current clamps |
11.8mm |
| Output signal (max.) |
1000mV |
| Type B |
BNC plug |
| Width |
67mm |
