UNITRONIC® LIYCY UL/CSA cables are largely similar to the UNITRONIC® LIYCY cables but the sheath colour is dark grey (chrome). Because of the UL/CSA approval, the cable is used for wiring appliances, machinery and plant which are intended for export into the North American market.
| Type |
Data Cable |
| AWG max. |
26 |
| Bend radius |
For flexible use: 15 x external dia. |
| Bend radius (no. of ODs for fixed installation) |
6 |
| Bend radius (no. of ODs for flexible installation) |
15 |
| Cable features |
Flame-retardant |
| Certification marks |
VDE 0815 |
| Core layout |
7-strand |
| Cross section (each core) |
0.14mm² |
| Factory colour |
Grey |
| Halogen-free |
No |
| Insulation material |
PVC |
| Max. length sold by the metre |
305m |
| Max. temperature range (fixed installation) |
+80°C |
| Max. temperature range (flexible installation) |
+70°C |
| Min. temperature range (fixed installation) |
-40°C |
| Min. temperature range (flexible installation) |
-5°C |
| Misc Attribute 1 |
UNITRONIC® LiYY UL/CSA DIN |
| Misc Attribute 2 |
UNITRONIC® LiYY A |
| No. of leads |
8 |
| Nominal voltage (details) |
300V |
| Outside Ø |
5.10mm |
| Packaged |
No |
| Peak operating voltage |
250 V (not for heavy current applications) |
| Shielded |
No |
| Sold per metre |
Yes |
| Temperature range |
When fixed: -30 - +80°C |
| Wire ID code |
47100 |
