Makita offers the DJV184Z cordless jigsaw, a versatile power tool suitable for cutting various materials. This 18V jigsaw is compact and lightweight, enhancing portability and ease of use. Ideal for woodworking and DIY projects, it provides precise and efficient cutting without the need for a power outlet.
| Voltage |
18V |
| Type |
Cordless jigsaw |
| Strokes Per Minute |
3000 /min |
| Battery Chemistry (Ni-Cd / Ni-MH / Li-ion) |
Li-ion |
| Capacity Aluminium |
20mm |
| Cutting depth (max.) (aluminium) |
20mm |
| Cutting depth (max.) (steel) |
10mm |
| Cutting depth (max.) (wood) |
135mm |
| Dim |
(L x W x H) 259 x 78 x 205 mm |
| Height |
205mm |
| Length |
259mm |
| Length of Stroke |
23mm |
| Max. Bevel Range (Left) |
0 - 45 º |
| Max. Bevel Range (Right) |
0 - 45 º |
| Max. Cutting Capacity in Steel (90°) |
10mm |
| Max. Cutting Capacity in Wood (90°) |
135mm |
| Noise Uncertainty (K Factor) |
3 dB(A) |
| Nominal Battery Voltage |
18 V |
| Product Dimensions (L x W x H): |
259 x 77 x 205 mm |
| Product net weight |
1.7kg |
| Rack size |
483 mm (19") |
| Sound Power Level (LWA) |
93 dB(A) |
| Sound Pressure Level (LpA) |
85 dB(A) |
| Strokes per Minute (SPM) |
0 - 3000 min?¹ |
| Tool weight with battery |
2.1 - 2.4kg |
| Upstroke (max.) |
23mm |
| Vacuum cleaner connection Ø in / out |
23 / 28mm |
| Vibration Level, Cutting Boards |
7,4 m/s² |
| Vibration Level, Cutting Sheet Metal |
5,1 m/s² |
| Vibration Uncertainty (K Factor), Cutting Boards |
1,5 m/s² |
| Vibration Uncertainty (K Factor), Cutting Sheet Metal |
1,5 m/s² |
| Weight |
2.1kg |
| Weight, information |
without rechargeable battery |
| Width |
78mm |
