The Siemens 5SU13546KK16 RCBO is a 2-pin circuit protection device rated for 16 A at 230 V, with a residual current of 0.03 A. It combines the functions of a circuit breaker and a residual current device, providing protection against both overloads and earth faults. Typical applications include residential and commercial electrical installations where safety and reliability are crucial.
Type |
RCBO |
Depth |
77mm |
Differential current rating |
0.03A |
Dim |
(W x H x D) 36 x 90 x 77 mm |
Factory colour |
Grey |
Height |
90mm |
Misc Attribute |
Switch-off description: without delay |
Nominal current |
16A |
Nominal current - rounded value |
16A |
Nominal voltage |
230V |
Number of pins |
2 |
Operating voltage |
230V AC |
Release characteristics |
B |
Switch-off capacity |
10kA |
Weight |
0 |
Width |
36mm |
