The Siemens 5SV31116 5SV3111-6 RCCB is a 2-pin residual current circuit breaker rated at 16 A with a leakage current sensitivity of 0.01 A at 230 V. It offers reliable protection against electrical faults, enhancing safety in residential and commercial electrical systems. Typical applications include safeguarding circuits in homes and office buildings to prevent electrical shocks and fire hazards.
| Type |
RCCB |
| Additional equipment possible |
TRUE |
| Built-in depth |
70mm |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.01A |
| Dim |
(W x H x D) 36 x 90 x 70 mm |
| Factory colour |
Grey |
| Frequency |
50 Hz |
| Height |
90mm |
| Leakage current type |
A |
| Misc Attribute |
Design of the product: without delay; Mounting Type: DIN rail |
| Mounting method |
DIN rail |
| Nominal current |
16A |
| Nominal current - rounded value |
16A |
| Nominal voltage |
230V |
| Number of pins |
2 |
| Number of Poles |
2 |
| Rated Current |
16A |
| Rated fault current |
0.01A |
| Rated voltage |
230V |
| Release characteristics |
A |
| RoHS-compliant |
Yes |
| Selective protection |
FALSE |
| Short-circuit breaking capacity (Icw) |
10kA |
| Short-time delayed tripping |
FALSE |
| Surge current capacity |
1kA |
| Switch-off capacity |
0.5kA |
| Voltage type |
AC |
| Weight |
0 |
| Width |
36mm |
| Width in number of modular spacings |
2 |
| With interlocking device |
TRUE |
